IPossibility of driving LED dies independently allows scanning a broad spectral range. Standard LMSNT 6-element multi wavelength LED array comprised of LED dies with peak wavelengths 1.3, 1.4, 1.6, 1.7, 1.9 and 2.1 μm covers the range from 1.3 μm to 2.1 μm.
The 6-element multi wavelength LED array is available in the following packages:
• TO-5 with a cap (with a glass window) - Lms13-14-16-17-19-21LED-6M;
• TO-8 with a thermoelectric module with a cap (with a glass window) - Lms13-14-16-17-19-21LED-6M-TEM.
Standard multi-wavelength matrices
Chip Type | Peak Wavelength( ㎛) | FWHM(nm) | Optical power (pulse, mW) | Voltage (V) | Current (Max mA) | Operating temperature( ℃) |
(min~max) | (min~max) | (min-typ) | (Min~max) | 1000 | +5 ~ +90 | |
Lms13LED | 1.25 ~ 1.33 | 70 ~ 100 | 15 ~ 17 | 1.3 ~ 1.6 | 1000 | +5 ~ +90 |
Lms14LED | 1.40 ~ 1.49 | 90 ~ 120 | 12 ~ 14 | 1.2 ~ 1.5 | 1000 | +5 ~ +90 |
Lms16LED | 1.60 ~ 1.69 | 120 ~ 150 | 12 ~ 14 | 1.1 ~ 1.4 | 1000 | +5 ~ +90 |
Lms17LED | 1.70 ~ 1.79 | 160 ~ 220 | 9 ~ 10 | 1.1 ~ 1.4 | 1000 | +5 ~ +90 |
Lms19LED | 1.90 ~ 1.99 | 100 ~ 200 | 5 ~ 6 | 1.2 ~ 2.8 | 1000 | +5 ~ +90 |
Lms21LED | 2.10 ~ 2.19 | 150 ~ 250 | 5 ~ 7 | 1.2 ~ 2.8 | 1000 | +5 ~ +90 |
